XÍCH TẢI CÔNG NGHIỆP CÁC LOẠI

ISO
Chain
NO.

Pitch

Roller Diameter

Width Between Inner Plates

Pin Diameter

Plate Thickness

late Depth

Pin Length

Transv-
erse Pitch

Average Tensile Strength

Tensile Stren-
gth min

Weigtht Per Meter

P

Dr
max

W
min

D
max

T
max

H
max

L
max

Lc
max

L3
max

C

KN

KN

Kg/m

mm

mm

mm

mm

mm

mm

mm

mm

mm

mm

C08A-1

C08A-2

C08A-3

12.70

7.92

7.85

3.98

1.50

12.07

17.80

32.30

46.70

18.85

33.30

47.50

19.05

34.10

48.60

14.38

17.80

35.60

53.40

13.80

27.60

41.40

0.73

1.46

2.20

C10A-1

C10A-2

C10A-3

15.875

10.16

9.40

5.09

2.03

15.09

21.80

39.90

57.90

22.90

41.10

59.15

23.10

42.40

60.45

18.11

29.20

58.40

87.67

21.80

43.60

65.40

1.19

2.30

3.57

C12A-1

C12A-2

C12A-3

19.05

11.91

12.57

5.96

2.42

18.08

26.90

49.80

72.60

28.20

51.15

74.45

28.80

52.85

76.15

22.78

41.60

83.20

124.80

31.10

62.30

93.40

1.76

3.49

5.20

C16A-1

C16A-2

C16A-3

25.40

15.88

15.75

7.94

3.25

24.13

33.50

62.70

91.90

36.00

62.25

94.45

36.50

67.95

97.15

29.29

72.00

142.00

216.00

55.60

111.20

166.80

3.08

6.08

9.13

C20A-1

C20A-2

C20A-3

31.75

19.05

18.90

9.54

4.00

30.18

41.10

77.00

113.00

43.40

79.30

115.25

45.20

82.10

118.05

35.76

110.20

220.40

330.00

86.70

173.50

260.20

4.56

8.87

13.5

C24A-1

C24A-2

C24A-3

38.10

22.23

25.22

11.11

4.80

36.20

50.80

96.30

141.70

54.30

99.75

145.25

56.30

103.55

149.05

45.44

157.20

314.10

417.60

124.60

249.10

373.70

6.38

13.40

20.00

C28A-1

C28A-2

C28A-3

44.45

25.40

25.22

12.71

5.60

42.24

54.90

103.60

152.40

59.15

107.95

156.95

60.05

112.65

161.65

48.87

210.00

420.00

630.00

169.00

338.10

507.10

8.55

17.00

25.40

C32A-1

C32A-2

C32A-3

50.80

28.58

31.55

14.29

6.40

48.26

65.50

124.20

182.90

69.60

128.25

186.90

71.90

133.05

191.70

58.55

275.00

550.00

825.00

222.40

444.80

667.20

11.53

22.90

34.30

ISO
Chain NO.

Pitch

Roller Diameter

Width Between Inner Plates

Pin Diameter

Plate Thickness

Plate Depth

Pin Length

Transv-
erse Pitch

Average Tensile Strength

Tensile Streng-
th min

Weigtht Per Meter

P

Dr
max

W
min

D
max

T1
max

T2
max

H
max

L
max

Lc
max

L3
max

C

KN

KN

Kg/m

mm

mm

mm

mm

mm

mm

mm

mm

mm

mm

mm

C08B-1

C08B-2

C08B-3

12.70

8.51

7.75

4.45

1.60

1.60

11.81

17.00

31.00

44.90

18.50

32.50

46.40

18.50

33.80

47.80

13.92

18.60

35.00

48.80

17.80

31.10

44.50

0.86

1.66

2.46

C10B-1

C10B-2

C10B-3

15.875

10.16

9.65

5.08

1.70

1.70

14.73

19.60

36.20

52.80

21.05

37.65

54.20

21.35

39.65

56.30

16.59

25.60

50.20

75.80

22.20

44.50

66.70

1.20

2.34

3.60

C12B-1

C12B-2

C12B-3

19.05

12.07

11.68

5.72

1.85

1.85

16.13

22.70

42.20

61.70

24.35

43.80

63.30

25.05

46.50

66.20

19.46

30.30

60.30

91.00

28.90

57.80

86.70

1.46

2.93

4.45

C16B-1

C16B-2

C16B-3

25.40

15.88

17.02

8.28

3.10

4.15

21.08

36.10

68.00

99.90

37.95

69.90

101.80

39.05

73.90

106.00

31.88

68.80

136.00

205.60

60.00

106.00

160.00

3.10

6.22

9.20

C20B-1

C20B-2

C20B-3

31.75

19.05

19.56

10.19

3.70

4.60

26.42

43.20

79.70

116.10

44.67

81.07

117.40

48.57

86.57

123.15

36.45

108.60

208.40

285.30

95.00

170.00

250.00

4.56

9.06

13.50

C24B-1

C24B-2

C24B-3

38.10

25.40

25.40

14.63

5.20

6.00

33.40

53.40

101.80

150.20

58.20

106.65

155.20

62.30

112.95

161.50

48.36

176.80

322.60

489.50

160.00

280.00

425.00

8.63

16.84

25.00

C28B-1

C28B-2

C28B-3

44.45

27.94

30.99

15.90

6.30

7.50

37.08

65.10

124.70

184.30

70.00

129.57

189.17

74.60

136.97

196.57

59.56

223.60

407.50

610.00

200.00

360.00

530.00

10.96

21.60

32.39

C32B-1

C32B-2

C32B-3

50.80

29.21

30.99

17.81

6.30

7.00

42.29

67.40

126.00

184.50

71.40

129.97

188.50

75.10

136.87

195.40

58.55

278.20

510.30

771.20

250.00

450.00

670.00

11.81

23.16

34.46
