watt drive
A suitable drive solution for each application.
Geared motors, Industrial motors, Frequency inverters, Special gear units |
|
|
|
 |
|
|
|
|
|
|
|
|
  |
 |
|
|
|
6
 |
|
|
|
|
|
|
| WATT MAS - Modular Drive System MAS |
Watt Drive offers a complete program of electric, electronic and mechanical drive technology both in the form of individual units or as a complete drive system.
We offer perfectly coordinated standard products!
By expanding on top of our modular gear system we are able to meet the highest demands of our customers with the most modern motor and inverter technologies. Our special tooth formation and surface finish guarantee the highest bearing capacity resulting in smaller gear wheels at the same torque. In this manner smaller gear units are possible with an excellent power spectrum.Watt Drive geared motors really are spectacular!
The modular drive system MAS constitutes:
• Drive System
from Watt Brain Power, gear units, motors and
electonic drives
• Modular Drive Electronics
with frequency inverters for open loop, sensorless vector,
closed loop, torque and position control as well as various
bus systems.
• Modular Motor Systems
including system motors and servomotors based on
modular design concepts that can be simply tuned to meet
the needs of the customer.
• Modular Gear System
in particular for servo drive systems, low backlash, quiet,
compact
|
|
| Gear units and geared motors - Geared motors of the highest quality |
Watt Drive gear units and geared motors are based on the WATT MAS Gear and Motor Systems.
Using the WATT MAS gear and motor system, it is possible to implement reliable and economical solutions in a very short time that are customized to your particular call for use.
The characteristics of modular Watt Drive gear technology meet all the criteria of the most modern drive systems:
• Outstanding power spectrum
• Minimal back lash
• Excellent running
• Smoothness
• Diverse mounting possibilities
• Maximum operational safety
• High variability
• Customer-oriented torque / overall size
|
|
 |
 |
 |
| Helical geared motors
|
The Uniblock design - foot and flange execution in one case!
Uniblock design for foot and flange mounting. Gear case machined on all sides for universal application.
Revolutionary new gearing geometry here and in all the other models results in exceptional running smoothness. For special environmental conditions the gear unit can be fitted with two shaft seals.
Technical Data:
Number of sizes: 18
Power range: 0.12 - 55kW
Output torque range: 27 - 14,000Nm
Ratio: 0.8 - 8,600
Output option: output shaft
Assembly/mounting: uniblock, flange, foot
|
|
| Shaft mounted geared motors
|
The drive for conveyor technology!
In addition to the benefits of the parallel-mounted geared motor, this is an extremely economical model, especially for shaft and flange mounting.
Special double-chamber shaft seals developed by Watt Drive that guarantee complete leak tightness are used as standard, as in the parallel-shaft geared motor.
Technical Data:
Number of sizes: 5
Power range: 0.12 - 22kW
Output torque range: 48 - 2,800Nm
Ratio: 0.8 - 4,000
Output option: output shaft, output shaft on both sides, hollow shaft, hollow shaft with shrink disc, agitaor drive execution
Assembly/mounting: support, flange
|
|
| Parallel shaft geared motors
|
Various mounting and possible applications by Uniblock - gear case!
The uniblock gear case machined on all sides, the particularly stable case and minimum outside dimensions enable diverse mounting options and applications.
As a result, these motors often form an integral part of our customers’ machine designs. High precision manufacturing and top gearing quality guarantee minimum backlash in Watt Drive gear units.
Technical Data:
Number of sizes: 4
Power range: 0.12 - 55kW
Output torque range: 2,800 - 14,000Nm
Ratio: 6 - 18,000
Output option: output shaft, output shaft on both sides, hollow shaft, hollow shaft with shrink disc, agitator drive execution
Assembly/mounting: uniblock, flange |
|
 |
 |
 |
| Helical worm geared motors
|
Tough, compact, eye-catching !
Due to the unique combination of newly developed worm wheel material with special lubricants, extreme precision and optimized shapes, this powerful motor achieves comparatively high levels of efficiency and torque. The case machined on all sides enables diverse mounting options.
Double-chamber shaft seals made of HNBR are used as standard, guaranteeing complete leak tightness.
Technical Data:
Number of sizes: 7
Power range: 0.12 - 7.5kW
Output torque range: 30 - 1,400Nm
Ratio: 3 - 3,400
Output option: output shaft, output shaft on both sides, hollow shaft, hollow shaft with shrink disc
Assembly/mounting: uniblock, flange, torque arm |
|
| Helical bevel geared motors
|
Compact, eye-catching, unique for limited space issue !
The compact and structureoptimized gear case of the helical bevel gears distinguish themselves by being
machined on all sides and are therefore, ready for a variety of mounting options and applications. The unique motorposition provides an almost flat and easy to mount on ”machine-interface”.
In the basic executions the gear boxes are designed as 2 stage gears up to the size K. 75 (1.250Nm). The bigger gear boxes, beginning with the K. 77 (1.500Nm) are designed as 3 stage gears.
Technical Data:
Number of sizes: 10
Power range: 0.12 - 55kW
Output torque range: 100 - 14,000Nm
Ratio: 5.5 - 8,600
Output option: output shaft, output shaft on both sides, hollow shaft, hollow shaft with shrink disc, agitator drive execution
Assembly/mounting: uniblock, flange, torque arm |
|
| Angle parallel shaft geared motors
|
Ruggedness for hard industry application!
These angle-parallel-shaft gears are machined on all sides and the primary gear unit with motor can be turned through 90°. As a result the best motor position for the application can be found. This feature also allows the housing to be ultra-flat.
In addition, there are models with support noses for shaft-mounted applications and flanges for agitators, etc.
Technical Data:
Number of sizes: 5
Power range: 0.12 - 45kW
Output torque range: 1,200 - 10,000Nm
Ratio: 10 - 7,100
Output option: output shaft, output shaft on both sides, hollow shaft, hollow shaft with shrink disc, agitator drive execution
Assembly/mounting: uniblock, support, flange |
|
| EUSAS-System motors |
A Motor for 100Hz Characteristic and Any Voltage Worldwide!
WATT EUSAS motors are top quality three-phase AC industrial models from Watt Drive’s customer-oriented modular WATT MAS motor system.
EUSAS stands for EUROPA - USA - ASIEN and means that the wide voltage range and simple voltage selector in the terminal box enable the motor to be operated with virtually any supply voltage and frequency worldwide.
Connection types:
All world voltages are possible in the range from 3x190-210V (DD), 330-365V (YY), 380-420V (D) and 660-690V (Y) for 50 and 60Hz.
The board with nine terminals enables star (Y), delta (D), double star (YY) and double delta (DD) connection of the Watt Drive motor.
|
|
 |
 |
 |
| Integral motors
|
The EUSAS integral motor is part of the Watt motor system. All features and benefits have been implemented and further developed. The motor is robust, in keeping with the high demands made by the industry and in the short term is capable of excessive loads.
The motors are equipped with a reinforced suspension and are directly built into the gear units, resulting in a very short, compact design.
The standard is equipped with a brake end plate as NDE-side (non driven end side). By using the standardized motor modules (for more information see “Motor systems”), customer-specific solutions can be implemented quickly and economically.
Technical Data:
Possible number of poles: 2-, 4-, 6-, 8-, 4/2-, 8/4-, 6/4-, 6/2, 8/2-pole
IEC size: 63 - 250
Performance area 2-pole: 0,18 – 1,5kW
Performance area 4-pole: 0,12 – 55kW
Performance area 6-pole: 0,09 – 55kW
Performance area 8-pole: 0,04 – 22kW |
|
| Asynchronous servo motors
|
The Watt asynchronous servo motor is an evolutionary development based on the proven Watt-EUSAS-Motor. The new motor is now optimized for industrial drive tasks, requiring closed loop speed control in frequency inverters and having special demands:
- high dynamic during acceleration and deceleration as well on
the compensation of speed deviations
- high speed accuracy
- high mechanical and electrical robustness of the whole drive
system
- large speed range
- high accuracy of running (also at low speed)
|
|
| IEC standard motors
|
Watt standard motors adhere to the following IEC standards:
Type WAG model B3 - (IEC - standard 72-1 DIN 42673)
Type WAF model B5 - (IEC - standard 72-2 DIN 42677)
Type WAC model B14 - (IEC - standard 72-2 DIN 42677)
The options in the motor system are also available in Watt norm motors.
Technical Data:
Possible number of poles: 2-, 4-, 6-, 8-, 4/2-, 8/4-, 6/4-, 6/2, 8/2-pole
IEC size: 63 - 315
Performance area 2-pole: 0,18 - 200kW
Performance area 4-pole: 0,12 - 200kW
Performance area 6-pole: 0,09 - 123kW
Performance area 8-pole: 0,04 - 7.5kW
|
|
| Drive Electronics |
The frequency inverter programs S-line, B-line, E-line and P-line consistently follow the same principle in the range of 0.2 to 90 kW as the Watt Drive modular drive systems. These frequency inverters distinguish themselves through their excellent control features, compact size, ease of use and very good communication skills. The differences between the four programs lie primarily in the control features and thus the starting torque and dynamic performance achieved. The S models are V/F controlled, while the B, E and P range consists of vector-controlled frequency inverters. The E-line offers implemented EMC filters and brake choppers in series, as well as many possible extensions for the digital and analog in- and outputs. Moreover an integrated SPS control is available. The P range features distributed intelligence e.g. for positioning tasks. This complete range of modular drive control units offers the technically best and most cost-effective drive solution for any requirement, from simple open loop control to top dynamic closed loop process control and positioning applications. Watt Drive is able to offer a complete range of modular drive control units and the most cost-effective drive solution for any requirement, from simple control and drive tasks to the control of top dynamic processes and positioning. |
|
 |
 |
 |
| Inverter E-line VFD-E
|
The modular frequency inverter VFD-E.
From the experiences made with S- and B-line there has been developed a new motor drive.
The targets were, integrated line filter and brake choppers, as well as an easy selection and handling, sturdiness and a modular drive philosophy, as to find an optimal solution in both economical and technical aspects on every demand for a motor drive.
Technical Data:
Voltage: 1 ~ 230V und 3 ~ 400V/460V
Control: U/f + SVC + VC
Area of performance single-phase: 0.25kW - 2.2kW [1/3HP to 3HP]
Area of performance three-phase: 0.4kW - 22kW [1/2HP up to 30HP] |
|
| Inverter S-line VFD-S
|
Integrated flexibility at a low price.
The frequency inverter VFD-S from the S-line program is particularly suitable for applications whereby cost-effectiveness plays a central role. However, it also offers many other opportunities, which are outstanding in this category, for example, motor slip compensation, parametric U/f characteristics, etc.
The VFD-S unites innovative technology, a high level of performance and functionality with a compact design and a wide scope of application. The simplest start up of operations, of use and parameterization distinguish this frequency inverter.
Technical Data:
Voltage: 1 ~ 230V und 3 ~ 400V/460V
Control: U/f (with slip compensation)
Area of performance single-phase: 0.25kW - 2.2kW [1/3HP to 3HP]
Area of performance three-phase: 0.75kW - 2.2kW [1HP to 3HP] |
|
| Inverter B-line VFD-B
|
The multi-talent for high torque.
The VFD-B power packet from the B-line range with the new sensorless vector control (SVC) provides a superior torque for demanding applications consistently over the whole performance range. This SVC is supported by a static/dynamic motor autotuning in order to adapt control to any circumstances occuring during operations of the specific application in an optimal manner. The frequent spread of standard factory models of machine parameters is thus wholly compensated. This internal control procedure means that especially in the lower torque range a previously unattainable torque curve is possible.With the optional feedback card, the VFD-B is perfect for complex closed loop control tasks.
Technical Data:
Voltage: 1 ~ 230V und 3 ~ 400V/460V
Control: U/f + SVC + VC
Area of performance single-phase: 0.75kW - 2.2kW [1HP to 3HP]
Area of performance three-phase: 0.75kW - 75kW [1HP to 100HP] |
|
 |
|
|
| Inverter P-line P6000
|
The unique, intelligent all-rounder.
The frequency inverter P6000 enhances the functionality of the frequency inverter range. With its modular design, flexible programmability and integrated positioning control, the user has the possibility to transfer control intelligence to the inverter and therefore relieve SPS for more integral tasks.
Technical Data:
Voltage: 1 ~ 230V und 3 ~ 400V/460V
Control: U/F, Torque- and Position control
Area of performance single-phase: 0.75kW - 1.5kW [1HP to 2HP]
Area of performance three-phase: 0.75kW - 90kW [1HP to 120HP] |
|
|
|
| Agitator drives |
Agitator and extruder drives - reliability that meets the highest demands.
The agitaor drives of the Watt Drive company are part of the modular gear system in the MAS program.
Aim of development was maximum sealing protection and a long storage product life while at the same time providing extremely reliable radial and/or axial power.
What resulted from these guidelines were gear units that alongside these requirements offer these further optional features:
• Rust-protected brakes
• Greater corrosion protection (special coating for increased atmospheric conditions)
• A variety of motor options (auxiliary heating system, …)
• Niro nameplates
• Oil inspection glass
• If necessary, special lubricant
• High pressure ventilation valve
• Oil level sensor
• ...
|
|
| Customer specific drive solutions |
Important factors at special solutions in drive technology are the attained delivery time and the quality of the delivered drives. Beginning with the project inquiry up to the delivery of the product Watt Drive serves his customers with high application know-how. From simple modifications like special output shafts up to complete special gears countless problems are solved at Watt Drive together with the customer.
Examples:
• New gearings – special ratios for the standard gear resp. new gearings for special gears
• Gear housings with special fixing possibilities
• Gear housings made of ductile iron
• Gear housings with water cooling
• Special base-, flange, output and hollow shaft dimensions
• Special sealing systems
• .....
|
| Drive engineering software |
The software ”cat4CAD” enables simple interactive product selection from the entire WATT MAS range. It´s possible to generate a complete WATT drive system consisting of a geared motor and suitable drive electronics from the modular WATT frequency inverter system.
Start your electronic product selection - www.cat4CAD.com !
|
|
 |
|
|
|
|
|
| Navigation |
 |
|
|
| Offer Profile |
Watt Drive is active in the drive technology sector, where it is involved in the development, manufacture and sale of machine drives, specialising in geared motors, AC motors, frequency inverters and complete drive systems.
Watt Drive systems move machinery and installations worldwide, and the company maintains branch offices and partners in all major industrial countries.
The company’s customers trust its high level of operational safety and technically sophisticated products coupled with flexibility and application-oriented solutions.
|
|
|
|
Gearboxes,speed reducers,planetary gear unit,modular speed reducer,gearmotors or gearbox with motor, ac motors,roller table motors made from Ningbo donly transmission equipment co.,ltd. have been widely used in various industries including steel maker, cement,building material, carne, light industry,mining,power,wind power,chemical,sugar extruder,plastic and rubber and so on.
|
|
| |
|
|
|
|
|
| |
